Pentair Stark B4110 Transformer

Pentair Stark B4110 Transformer  -  120 vac to 24 vac  -  100 watts

• Certification: UL Listed (meets or exceeds the requirements set forth in UL Standard for Safety UL5085)
• Power: 120 VAC to 24 VAC, 100 Watt
• Operation: Single circuit transformer
• Circuit Protector: Manual reset overload protection
• Input: 120 VAZ / 60 HZ.
• Output: 24 VAC
• Max rated load: 100 VA @ 24 VAC
• Enclosure: NEMA 3R
• Installation: Mounting brackets
• Wiring: ½” Knockouts in wiring compartment
• Part Number: B4110
• Manufacture: Made in USA
• Included: Transformer with installation instructions

Product Guide

Notes:
1. Wire and wire nuts provided by others.
2. Installation by others.
3. Installation to be in accordance with local codes.
4. A class 2 transformer may be connected to any resistive load at or below its’ maximum output rating.
5. National Electric Code (NEC) requires any class 2 single circuit to be limited to 100 VA at 24 VAC.
